fabiosun

I did not in that way i measured 3.3v only putting stuff as I said in previous message to you if you can’t find after my breakfast I will search or write again for it @meina222

welcome here many of us have had success 😉

io direi anche solo avvicinarsi l'unica variabile che puo' essere fumogena e' l'utilizzo di RTX ma anche senza il numero di cuda cores presenti e' strabiliante Sempre se non li abbiano cambiati....che in passato e' già successo vedremo

@meina222 i have no tb ssdt on baremetal because i have to modify the one used in vm i think only @iGPU is studying in this field

Also with big failure Nvidia had in the past with integrated GPU in MacBook or similar...

It amazes me that a card of those literally runs around as power to the top of the range of the New MacPro 2019 .. And a professional user in the post effects production or SFX business takes this into account ...

OT What do you think of Nvidia's new graphics cards? It is a big pity that there is no support for Nvdia in OSX

you find in your debug log do not take MMIO from others config 😉

@meina222only for the sake of testing you could disable cccx or similar name you should have in advanced CPU BIOS settings leaving ON SMT part... But in this case performance should be worst for you However nice catch 🙂

GFX0 HDAU search in ioreg this with/without ssdt with/without weg I do not know other stuff yo are using in your config so I can't be more accurate

@meina222 if you have understood the elements used in your ssdt, to check you can verify them in your ioreg

Ciao Dani Mac e benvenuto e chi non vorrebbe di quelli presenti nel forum?😂

@iGPU yes it works i use 00000000 then enter in recovery and clear sip and nvram from there this could be need of additional quirk like avoidruntime defrag if you do not use it but all this is the weaker part in our effort to have a perfect or almost perfect system and all of you are more lucky than me because you do not use a Nvidia gpu

That quirk is a sort of nullcpupowermanagement.kext used in the past for cpu not supported by osx today i will verify our kernel patches because i think some differences is there

@meina222i like your programmer way to explain and to try to solve problem also @iGPU way is similar and i think you have given a bit to improve this thread thank you now a simple way to explain and sorry to all if sometimes i seems to be rude..it is only my english... more 1 we have in our debug better is because all that area are in OSX avaibility when an ‘area’ is on 0 in debug and OSX try to write there or use it for its tasks..system hangs about @Driftwood problem i have always said i am testing high sierra, mojave, catalina and for this when you reach your gold situation no problem at all gold situation means nvram ok sip ok bios ok config ok if one of this fails problem happens and to solve you have to be more drastic And you have to reset sip, in recovery and in config..to achieve and optimal condition this is our big and common problem.

@meina222 idk if they are excellent questions or not but it should be the questions all users should do to theirself before starting to play with those areas about your point 5) no all AMD platform need of devirtualizemmio stuff and often if you use in a system that does not neet it, system hangs

I think now you have understood what I am saying from a bit also for the sake of testing all of this should be apply also on different OSX to be proved solid rock combinations 😊

Test: 1) what does devirtualizemmio quirk does? 2) which means to on or to off it? 3) skip 0 what does it mean in the debug? 4) skip1 what does it mean in the debug? 5) a system that does not need of that quirks use or not those mmio area/pages? starting from here imho should be a common task😊

All skilled people should analyze what devirtualizemmio on does and the meaning to add whitelist address on our config. this also comparing with system that boots fine without that quirk which is optimal situation we can’t achieve so our goal is to free for OSX all address and page we can How? testing

i have also your debug..I am completing in this hour that list @meina222 i will add also system in which that schema works..and would be useful also bios configuration

00:768 00:014 OCABC: RTDFRG 1 DEVMMIO 1 NOSU 0 NOVRWR 0 NOSB 0 NOHBMAP 0 SMSLIDE 1 WRUNPROT 1 12:598 00:012 OCABC: MMIO devirt 0xCB100000 (0x81 pages, 0x8000000000000001) skip 1 12:608 00:009 OCABC: MMIO devirt 0xD7180000 (0x81 pages, 0x8000000000000001) skip 1 12:617 00:009 OCABC: MMIO devirt 0xE3180000 (0x81 pages, 0x8000000000000001) skip 1 12:627 00:009 OCABC: MMIO devirt 0xE3300000 (0x100 pages, 0x8000000000000001) skip 1 12:636 00:009 OCABC: MMIO devirt 0xEF100000 (0x181 pages, 0x8000000000000001) skip 1 12:645 00:009 OCABC: MMIO devirt 0xFEA00000 (0x100 pages, 0x8000000000000001) skip 1 12:655 00:009 OCABC: MMIO devirt 0xFEC00000 (0x1 pages, 0x8000000000000001) skip 1 12:664 00:009 OCABC: MMIO devirt 0xFEC10000 (0x1 pages, 0x8000000000000001) skip 1 12:673 00:009 OCABC: MMIO devirt 0xFED00000 (0x1 pages, 0x8000000000000001) skip 1 12:683 00:009 OCABC: MMIO devirt 0xFED40000 (0x5 pages, 0x8000000000000001) skip 1 12:692 00:009 OCABC: MMIO devirt 0xFED80000 (0x10 pages, 0x8000000000000001) skip 1 12:701 00:009 OCABC: MMIO devirt 0xFEDC2000 (0xE pages, 0x8000000000000001) skip 1 12:711 00:009 OCABC: MMIO devirt 0xFEDD4000 (0x2 pages, 0x8000000000000001) skip 1 12:720 00:009 OCABC: MMIO devirt 0xFEE00000 (0x100 pages, 0x8000000000000001) skip 0 12:730 00:009 OCABC: MMIO devirt 0xFF000000 (0x1000 pages, 0x8000000000000001) skip 1 12:739 00:009 OCABC: MMIO devirt 0x10000000000 (0x10400 pages, 0x8000000000000001) skip 0 12:749 00:009 OCABC: MMIO devirt 0x2BF40000000 (0x10400 pages, 0x8000000000000001) skip 0 12:758 00:009 OCABC: MMIO devirt 0x47E80000000 (0x10400 pages, 0x8000000000000001) skip 0 12:768 00:009 OCABC: MMIO devirt 0x63DC0000000 (0x10400 pages, 0x8000000000000001) skip 0 Driftwood Asrock TRX40 Creator MMIO Schema 4G on 00:768 00:014 OCABC: RTDFRG 1 DEVMMIO 1 NOSU 0 NOVRWR 0 NOSB 0 NOHBMAP 0 SMSLIDE 1 WRUNPROT 1 27:377 00:016 OCABC: MMIO devirt 0xE2100000 (0x81 pages, 0x8000000000000001) skip 1 27:398 00:021 OCABC: MMIO devirt 0xE3180000 (0x81 pages, 0x8000000000000001) skip 1 27:419 00:021 OCABC: MMIO devirt 0xEF100000 (0x181 pages, 0x8000000000000001) skip 1 27:435 00:015 OCABC: MMIO devirt 0xFA180000 (0x81 pages, 0x8000000000000001) skip 1 27:451 00:015 OCABC: MMIO devirt 0xFA300000 (0x100 pages, 0x8000000000000001) skip 1 27:471 00:020 OCABC: MMIO devirt 0xFEA00000 (0x100 pages, 0x8000000000000001) skip 1 27:487 00:015 OCABC: MMIO devirt 0xFEC00000 (0x1 pages, 0x8000000000000001) skip 1 27:503 00:015 OCABC: MMIO devirt 0xFEC10000 (0x1 pages, 0x8000000000000001) skip 1 27:518 00:015 OCABC: MMIO devirt 0xFED00000 (0x1 pages, 0x8000000000000001) skip 1 27:539 00:020 OCABC: MMIO devirt 0xFED40000 (0x5 pages, 0x8000000000000001) skip 1 27:555 00:015 OCABC: MMIO devirt 0xFED80000 (0x10 pages, 0x8000000000000001) skip 1 27:570 00:015 OCABC: MMIO devirt 0xFEDC2000 (0xE pages, 0x8000000000000001) skip 1 27:586 00:015 OCABC: MMIO devirt 0xFEDD4000 (0x2 pages, 0x8000000000000001) skip 1 27:601 00:015 OCABC: MMIO devirt 0xFEE00000 (0x100 pages, 0x8000000000000001) skip 0 27:617 00:015 OCABC: MMIO devirt 0xFF000000 (0x1000 pages, 0x8000000000000001) skip 1 27:632 00:015 OCABC: MMIO devirt 0x4040000000 (0x10400 pages, 0x8000000000000001) skip 1 27:654 00:021 OCABC: MMIO devirt 0x8BB0000000 (0x10400 pages, 0x8000000000000001) skip 0 27:675 00:021 OCABC: MMIO devirt 0x8BE0000000 (0x10400 pages, 0x8000000000000001) skip 0 27:690 00:015 OCABC: MMIO devirt 0xD750000000 (0x10400 pages, 0x8000000000000001) skip 0 fabiosun MSI TRX40 Pro 10G MMIO Schema 4g on 04:245 00:025 OCABC: RTDFRG 1 DEVMMIO 1 NOSU 0 NOVRWR 0 NOSB 0 NOHBMAP 0 SMSLIDE 1 WRUNPROT 1 21:976 00:024 OCABC: MMIO devirt 0xE2100000 (0x81 pages, 0x8000000000000001) skip 0 22:002 00:025 OCABC: MMIO devirt 0xE3180000 (0x81 pages, 0x8000000000000001) skip 0 22:028 00:026 OCABC: MMIO devirt 0xEF100000 (0x181 pages, 0x8000000000000001) skip 0 22:053 00:024 OCABC: MMIO devirt 0xFA100000 (0x81 pages, 0x8000000000000001) skip 0 22:080 00:027 OCABC: MMIO devirt 0xFA200000 (0x100 pages, 0x8000000000000001) skip 0 22:105 00:025 OCABC: MMIO devirt 0xFEA00000 (0x100 pages, 0x8000000000000001) skip 0 22:131 00:026 OCABC: MMIO devirt 0xFEC00000 (0x1 pages, 0x8000000000000001) skip 0 22:156 00:024 OCABC: MMIO devirt 0xFEC10000 (0x1 pages, 0x8000000000000001) skip 0 22:183 00:026 OCABC: MMIO devirt 0xFED00000 (0x1 pages, 0x8000000000000001) skip 0 22:208 00:025 OCABC: MMIO devirt 0xFED40000 (0x5 pages, 0x8000000000000001) skip 0 22:234 00:025 OCABC: MMIO devirt 0xFED80000 (0x10 pages, 0x8000000000000001) skip 0 22:259 00:025 OCABC: MMIO devirt 0xFEDC2000 (0xE pages, 0x8000000000000001) skip 0 22:286 00:026 OCABC: MMIO devirt 0xFEDD4000 (0x2 pages, 0x8000000000000001) skip 0 22:312 00:025 OCABC: MMIO devirt 0xFEE00000 (0x100 pages, 0x8000000000000001) skip 0 22:338 00:025 OCABC: MMIO devirt 0xFF000000 (0x1000 pages, 0x8000000000000001) skip 0 22:363 00:025 OCABC: MMIO devirt 0x10000000000 (0x10400 pages, 0x8000000000000001) skip 0 22:390 00:027 OCABC: MMIO devirt 0x3CB90000000 (0x10400 pages, 0x8000000000000001) skip 0 22:416 00:025 OCABC: MMIO devirt 0x3CBC0000000 (0x10400 pages, 0x8000000000000001) skip 0 22:442 00:025 OCABC: MMIO devirt 0x69750000000 (0x10400 pages, 0x8000000000000001) skip 0 rressl Gigabyte TRX40 Aorus Extreme Schema MMIO devirt 0xB2100000 (0x81 pages, 0x8000000000000001) skip 0 MMIO devirt 0xB3180000 (0x81 pages, 0x8000000000000001) skip 0 MMIO devirt 0xEF100000 (0x181 pages, 0x8000000000000001) skip 1 MMIO devirt 0xFA180000 (0x81 pages, 0x8000000000000001) skip 1 MMIO devirt 0xFA300000 (0x100 pages, 0x8000000000000001) skip 1 MMIO devirt 0xFEA00000 (0x100 pages, 0x8000000000000001) skip 1 MMIO devirt 0xFEC00000 (0x1 pages, 0x8000000000000001) skip 1 MMIO devirt 0xFEC10000 (0x1 pages, 0x8000000000000001) skip 1 MMIO devirt 0xFED00000 (0x1 pages, 0x8000000000000001) skip 1 MMIO devirt 0xFED40000 (0x5 pages, 0x8000000000000001) skip 1 MMIO devirt 0xFED80000 (0x10 pages, 0x8000000000000001) skip 1 MMIO devirt 0xFEDC2000 (0xE pages, 0x8000000000000001) skip 1 MMIO devirt 0xFEDD4000 (0x2 pages, 0x8000000000000001) skip 1 MMIO devirt 0xFEE00000 (0x100 pages, 0x8000000000000001) skip 0 MMIO devirt 0xFF000000 (0x1000 pages, 0x8000000000000001) skip 1 MMIO devirt 0x4070000000 (0x10400 pages, 0x8000000000000001) skip 0 MMIO devirt 0x8BD0000000 (0x10400 pages, 0x8000000000000001) skip 0 MMIO devirt 0x8C00000000 (0x10400 pages, 0x8000000000000001) skip 0 MMIO devirt 0xD760000000 (0x10400 pages, 0x8000000000000001) skip 0 iGPU MSI TRX40 Creator Schema 4G off here some user data with different motherboard with all respect for vit.. but in the past they have also said patches were borked... so I would verify all thing I can and it is also possible to reserve some of those four to OS X as people do not need of DevirtualizeMMIO do

@Pavoto complete your useful answer @meina222it would be useful also an opencore debug txt to see all your nvmio and page used in it when you can if possible...otherwise people will take your config (not user which are actively here but who is not participating) and think to use your config as is 🙂 🙂 it is yet happened 😉

@meina222I can't see in any forum a complete discussion as we have here i see also many people are fighting this TRX40 success and I do not know why I agree with you that many parameters could have an important role on sleep/wake process..but..Asrock Creator ( @Driftwood) has a lot of hardware in it..so it could possible I see often an errors on MMIO debug process in people trying..but there every owner has the key..double checking it I think every board is good..and in my case the best one I like is yours 🙂

MSI trx40 Creator works...@driftwood has also working and he has done a complete video to prove it 🙂

@Ploddles your log archives is weird Do you touch it? a regular debug txt should start with debug open core version printed 00:000 00:000 OC: OpenCore DBG-061-2020-08-22 is loading in Optional mode (0/0)... 00:010 00:010 OC: Boot timestamp - 2020.08.31 13:24:34 00:021 00:010 OCCPU: MP services threads 64 (enabled 64) - Success 00:032 00:010 OCCPU: MP services Pkg 1 Cores 1 Threads 1 - Success 00:043 00:010 OCCPU: Found AMD Ryzen Threadripper 3970X 32-Core Processor 00:053 00:010 OCCPU: Signature 830F10 Stepping 0 Model 31 Family F Type 0 ExtModel 3 ExtFamily 8 uCode 0 00:164 00:111 OCCPU: FID 148 DID 8 Divisor 0 MaxBR 36 00:175 00:010 OCCPU: CPUFrequencyFromTSC 3700004522Hz 3700MHz 00:186 00:010 OCCPU: CPUFrequency 3700004522Hz 3700MHz 00:197 00:010 OCCPU: FSBFrequency 102777903Hz 102MHz 00:208 00:010 OCCPU: Pkg 1 Cores 32 Threads 64 00:219 00:011 OC: OcLoadNvramSupport... 00:231 00:011 OC: Deleting NVRAM 4D1EDE05-38C7-4A6A-9CC6-4BCCA8B38C14:UIScale - Not Found 00:242 00:011 OC: Deleting NVRAM 4D1EDE05-38C7-4A6A-9CC6-4BCCA8B38C14:DefaultBackgroundColor - Not Found 00:253 00:010 OC: Not deleting NVRAM 4D1FDA02-38C7-4A6A-9CC6-4BCCA8B30102:rtc-blacklist, matches add 00:264 00:011 OC: Deleting NVRAM 7C436110-AB2A-4BBB-A880-FE41995C9F82:boot-args - Not Found 00:276 00:011 OC: Setting NVRAM 4D1EDE05-38C7-4A6A-9CC6-4BCCA8B38C14:DefaultBackgroundColor - Success 00:289 00:012 OC: Setting NVRAM 4D1EDE05-38C7-4A6A-9CC6-4BCCA8B38C14:UIScale - Success 00:307 00:018 OC: Setting NVRAM 4D1FDA02-38C7-4A6A-9CC6-4BCCA8B30102:rtc-blacklist - Not Found 00:319 00:012 OC: Setting NVRAM 7C436110-AB2A-4BBB-A880-FE41995C9F82:SystemAudioVolume - Success 00:338 00:018 OC: Setting NVRAM 7C436110-AB2A-4BBB-A880-FE41995C9F82:boot-args - Success 00:351 00:013 OC: Setting NVRAM 7C436110-AB2A-4BBB-A880-FE41995C9F82:csr-active-config - Success 00:362 00:011 OC: Setting NVRAM 7C436110-AB2A-4BBB-A880-FE41995C9F82:nvda_drv - Success 00:380 00:017 OC: Setting NVRAM 7C436110-AB2A-4BBB-A880-FE41995C9F82:prev-lang:kbd - Success 00:398 00:017 OC: Setting NVRAM 7C436110-AB2A-4BBB-A880-FE41995C9F82:run-efi-updater - Success 00:408 00:010 OC: Current version is DBG-061-2020-08-22 00:419 00:010 OC: OcMiscMiddleInit... 00:435 00:016 OC: LoadHandle B556F498 with BootProtect in None mode - Success as this I mean
