fabiosun

EFI-clover-Shrisha 2.zipThis instead is my Clover working EFI with inside your MMIO whitelist

Archive.zip this (change ACPI folder and config.plist) in previous EFI posted

4g is ON,CSM OFF, UEFI on, Resize bar off? no overclock on your CPU I hope in BIOS?

OK MMIO is ok may I ask if this problem started adding a NVME new disk?

config.plist.zip try this

Ok now is all clear if nothing is broken..we will fix it here we fixed all problem for many trx40 users! 🙂

@shrishaour first problem is to have a proper MMIO list and to achieve it we have to find optimal bios setup and then stay fixed with it 🙂 then we will try to understand why your pc does not complete its installation have you downloaded a full installer of Monterey? if so which version? Have you ever had in this PC OSX working? thank you

questo errore lo devi correggere a mano, in pratica, o usare il driver o attivare l'opzione nella sezione corrispondente

@shrishafrom your log: 35:434 00:015 OCABC: MMIO devirt 0xC7100000 (0x81 pages, 0x8000000000000001) skip 0 35:442 00:008 OCABC: MMIO devirt 0xCF180000 (0x81 pages, 0x8000000000000001) skip 0 35:730 00:287 OCABC: MMIO devirt 0xD7180000 (0x81 pages, 0x8000000000000001) skip 0 35:734 00:004 OCABC: MMIO devirt 0xD7300000 (0x100 pages, 0x8000000000000001) skip 0 35:739 00:004 OCABC: MMIO devirt 0xDF100000 (0x181 pages, 0x8000000000000001) skip 0 35:748 00:008 OCABC: MMIO devirt 0xFEA00000 (0x100 pages, 0x8000000000000001) skip 1 35:757 00:009 OCABC: MMIO devirt 0xFEC00000 (0x1 pages, 0x8000000000000001) skip 1 35:766 00:008 OCABC: MMIO devirt 0xFEC10000 (0x1 pages, 0x8000000000000001) skip 1 35:776 00:010 OCABC: MMIO devirt 0xFED00000 (0x1 pages, 0x8000000000000001) skip 1 35:785 00:008 OCABC: MMIO devirt 0xFED40000 (0x5 pages, 0x8000000000000001) skip 1 35:794 00:008 OCABC: MMIO devirt 0xFED80000 (0x10 pages, 0x8000000000000001) skip 1 35:803 00:009 OCABC: MMIO devirt 0xFEDC2000 (0xE pages, 0x8000000000000001) skip 1 35:811 00:008 OCABC: MMIO devirt 0xFEDD4000 (0x2 pages, 0x8000000000000001) skip 1 35:820 00:009 OCABC: MMIO devirt 0xFEE00000 (0x100 pages, 0x8000000000000001) skip 1 35:829 00:008 OCABC: MMIO devirt 0xFF000000 (0x1000 pages, 0x8000000000000001) skip 1 35:838 00:009 OCABC: MMIO devirt 0x2040000000 (0x10400 pages, 0x8000000000000001) skip 0 35:847 00:008 OCABC: MMIO devirt 0x5770000000 (0x10400 pages, 0x8000000000000001) skip 0 35:857 00:010 OCABC: MMIO devirt 0x8EA0000000 (0x10400 pages, 0x8000000000000001) skip 0 35:866 00:008 OCABC: MMIO devirt 0xC5D0000000 (0x10400 pages, 0x8000000000000001) skip 0 Bios changement produced 5 skip 0 in first mmios of your list try this EFI I have adjusted your MMIO, reduced some kext (till we will able to boot fine) Added a couple of SSDTs I am assuming you are installing a full installer of Monterey 12.x (12.01, 12.1 or 12.2.x) if it hangs post as always a photo where it hangs and debug log txt file PS do not change bios settings from the latest try you did 🙂 EFI-Shrisha.zip

@shrishaI moved our messages in a more proper thread

because with new bios maybe also new MMIO to convert

post debug txt when you can also a Hang photo

https://chriswayg.gitbook.io/opencore-visual-beginners-guide/hackintosh-opinions/olarila-not-recommended @shrishait is not an our friend or user but a maintainer of OCAT guide (a tool to update easily your OpenCore EFI)

hi @shrisha you have to start with a bios settings then with an Opencore debug versionn you discover your MMIO list and you have to declare it in config as we did then If you change something in BIOS as 4G or Resize bar you have to check your debug again to see if first MMIO are changed it is better to use a vanilla method because our trx40 are pretty simple now to configure and we not need weird kext ingestion 🙂 I would also suggest you to update to latest your Motherboard bios to have latest agesa available for TRX40 AMD chipset

this is a problem 😛 try to create an USB with vanilla method problem you have now is a wrong NVRAM malfunction usually it is possible to solve powering off your system leave 4g On and try to boot fine again then post debug txt to check MMIO list

enabling it it changes a couple of mmio try if it starts and boots then post log to refine MMIO if you can post also your main BIOS settings

Now MMIO are fine use this in boot menu press space bar then Reset NVRAM then try to boot config.plist.zip post where it hangs Are you installing with a full installer USB? or in which way? Which OS? I have inserted patches from High Sierra to Monterey so it is not your problem In your bios have you 4g enabled? if no enable it and then re post debug log

config.plist.zip @shrisha use this and before and booting delete old logs in your EFi partition then post only new log created thank you

no need of your DSDT TRX40 works without using it only a SSDT could be useful We must to transform all skip 0 inside yellow square to skip 1 I will send you a config in few minutes you don't have to change then anything in your bios because MMIO are bios parameters dependant

@shrishanow here is lunch time I see your log from my phone it si wrong many of your mmio whitelist is bad we have to adjust them

EFI.zipTry with this and post debug txt file you can find in your EFi partition (also if it does not start well) thank you @shrisha

@shrishapost a your working EFi with OpenCore please

Per gli utenti AMD Siamo riusciti a far inserire allo sviluppatore alcune caratteristiche utili per noi utenti AMD Ringrazio gli utenti del forum che hanno fornito le loro configurazioni funzionanti che ho provveduto a trasformare nel formato indicato dallo sviluppatore! Di seguito un video che mostra le possibilità: AMD_OCAT.mp4

😓

same problem of previous beta...
