fabiosun

thanks @tomnic to point me to this test : Davinci resolve 17 beta3 fabio@fabios-iMac-Pro ~ % lipo -info /Applications/DaVinci\ Resolve/DaVinci\ Resolve.app/Contents/MacOS/Resolve Architectures in the fat file: /Applications/DaVinci Resolve/DaVinci Resolve.app/Contents/MacOS/Resolve are: x86_64 arm64 <--------- 🙂 Photoshop 2021: fabio@fabios-iMac-Pro ~ % lipo -info /Applications/Adobe\ Photoshop\ 2021/Adobe\ Photoshop\ 2021.app/Contents/MacOS/Adobe\ Photoshop\ 2021 Non-fat file: /Applications/Adobe Photoshop 2021/Adobe Photoshop 2021.app/Contents/MacOS/Adobe Photoshop 2021 is architecture: x86_64 Cinema 4d fabio@fabios-iMac-Pro ~ % lipo -info /Applications/Maxon\ Cinema\ 4D\ R23/Cinema\ 4D.app/Contents/MacOS/Cinema\ 4D Architectures in the fat file: /Applications/Maxon Cinema 4D R23/Cinema 4D.app/Contents/MacOS/Cinema 4D are: x86_64 arm64 <--------- 🙂 Cinebench 23 fabio@fabios-iMac-Pro ~ % lipo -info /Applications/Cinebench.app/Contents/MacOS/Cinebench Architectures in the fat file: /Applications/Cinebench.app/Contents/MacOS/Cinebench are: x86_64 arm64 arm64 <--------- 🙂 Image Capture (apple app) fabio@fabios-iMac-Pro ~ % lipo -info /System/Applications/Image\ Capture.app/Contents/MacOS/Image\ Capture Architectures in the fat file: /System/Applications/Image Capture.app/Contents/MacOS/Image Capture are: x86_64 arm64e <-------- 🙂 we have some hope 🙂

Ok venduto allora ti scrivo in privato

ti manca questo Kernelcache, ma onestamente io non la uso e non ho problemi ad aggiornare anche con clover più' vecchi dell'ultima versione..con un sistema tra l'altro teoricamente piu' problematico del tuo

scusa niente a colpo d'occhio mi aveva tratto in inganno che nel tuo config hai messo solo uno di quelli che sono settati su NO

Guarda a me non serve, ma il prezzo che fai e' ottimo se sei in una zona compatibile lo prendo io 🙂 ho letto ora Celio io Eur

la sezione quirks mi sembra un po' poverella prova a dare un'occhiata a questo link

Ciao la cartella Apple la puoi omettere..fatto io per te da 24 mb a circa 5 Mb se vedi 🙂

si la scatola dice 5 anni forse registrandosi al sito che zona di Roma? grazie

@Arrakis try without rebuidmap quirk.. or if you want try to adapt to your system EFI I have posted in @cleverhome thread with that you can install from scratch both Catalina and latest Big Sur

ciao ma e' ancora in garanzia? grazie

For debug in config misc/debug/target Put 3 instead of 67 Yes your USB’s are not working well for config differents I have enabled 2 kexts in kernel/add

with experience?? 😛

you can try to put them to 0 (no in config)..but system then hangs some combinations could also work..but many users leave them to zero...

on your OpenCore debug log search for MMIo inside I have put yes on many of them if you see also on 8 position and there you see 0 (it means no or a bad conversion..or you have changed something in system) so you have to recalculate your exact MMIO dinner time see you tomorrow..I hope you can try and solve additional simple things you have to do 😉

config-2.plist.zip try this and see if something happen also post your audio settings as you can see here

maybe 8 conversion is wrong remember, if you change bios option or card slot..it could change your mmio...

first two I do not know (maybe first error is due to your windows raid for wifi bt see here (beta support of intel stuff) audio should work as is (I mean onboard internal audio) check your mmio something is wrong see first 0 and check in config

sorry which ones? I have not seen the others

for your PS 😛 please if you want help you can donate to forum.. No one here accept personal donations to help people 😉 So if you want to donate use donation button and help the forum and his admin to grow 🙂 1) I have used my EFI and my kext try to put your ethernet kext and check the path in config.plist and in it 2) before turning it off.. 😛 put here latest debug..to check if MMIO are fine 3) you can use some apps to do it but I do not advice...uou can find a boot loader launcher also in this forum or in Insanelymac forum.. for me it is better to have different EFi

config-2.plist.zip I have set to yes some of them try to boot renaming this config properly and post newer debug log usually in config MMIO comment you can put the name in ex decimal this is useful to check if conversion is fine

I will insert it here

all this one: 0xE2180000 0xxxxxxxxx and so on

ok, I have some homework for you 52:972 00:064 OCABC: MMIO devirt 0xE2180000 (0x81 pages, 0x8000000000000001) skip 0 53:036 00:063 OCABC: MMIO devirt 0xE3180000 (0x81 pages, 0x8000000000000001) skip 0 53:108 00:072 OCABC: MMIO devirt 0xE3300000 (0x100 pages, 0x8000000000000001) skip 0 53:172 00:063 OCABC: MMIO devirt 0xE8300000 (0x181 pages, 0x8000000000000001) skip 0 53:235 00:063 OCABC: MMIO devirt 0xFA500000 (0x81 pages, 0x8000000000000001) skip 0 53:299 00:064 OCABC: MMIO devirt 0xFEA00000 (0x100 pages, 0x8000000000000001) skip 0 53:363 00:063 OCABC: MMIO devirt 0xFEC00000 (0x1 pages, 0x8000000000000001) skip 0 53:581 00:218 OCABC: MMIO devirt 0xFEC10000 (0x1 pages, 0x8000000000000001) skip 0 53:646 00:064 OCABC: MMIO devirt 0xFED00000 (0x1 pages, 0x8000000000000001) skip 0 53:710 00:064 OCABC: MMIO devirt 0xFED40000 (0x5 pages, 0x8000000000000001) skip 0 53:774 00:064 OCABC: MMIO devirt 0xFED80000 (0x10 pages, 0x8000000000000001) skip 0 53:838 00:063 OCABC: MMIO devirt 0xFEDC2000 (0xE pages, 0x8000000000000001) skip 0 53:902 00:063 OCABC: MMIO devirt 0xFEDD4000 (0x2 pages, 0x8000000000000001) skip 0 53:966 00:064 OCABC: MMIO devirt 0xFEE00000 (0x100 pages, 0x8000000000000001) skip 0 54:029 00:063 OCABC: MMIO devirt 0xFF000000 (0x1000 pages, 0x8000000000000001) skip 0 54:093 00:063 OCABC: MMIO devirt 0x10000000000 (0x10400 pages, 0x8000000000000001) skip 0 54:165 00:071 OCABC: MMIO devirt 0x12CA0000000 (0x10400 pages, 0x8000000000000001) skip 0 54:228 00:063 OCABC: MMIO devirt 0x12CD0000000 (0x10400 pages, 0x8000000000000001) skip 0 54:293 00:064 OCABC: MMIO devirt 0x15970000000 (0x10400 pages, 0x8000000000000001) skip 0 convert these MMIO from ex to decimal then we insert it in your config before try previous EFI In General MMIO is an optimisation , system must start also with all this to 0 thanks

replace completely please EFI 2.zip
