fabiosun

good morning guys 🙂 Italy won a beautiful football match with England and my second dose of Pfizer vaccine is fortunately also losing intensity tighter small problems it has produced in me. So I'll hopefully clarify it definitively. I understand that it is very frustrating to see "solutions" and to be told I cannot provide them. But, do you also know how much I spent for example to get out the patches for Monterey beta 1 stimulating, at times, perhaps, even in a heavy way, the managers of the same. having said that, in this space I will try to make myself better understood by talking exclusively about what is available at the moment. That is the official patches downloadable from the official AMD OSX Github. The patches are those valid up to Monterey Beta1 I will do a further reduction of the field and will think exclusively on systems ranging from Big Sur 11.4 to big Sur 11.5.beta 5 This discourse can be carried on up to Monterey beta 1 and, having an unreleased patch available also in Monterey beta 2. But let's stay with the facts. The schemes that I will propose are for clover bootloader. Patches used are the same for both bootloaders, obviously with the respective names useful for the two bootloaders that have different nomenclature for their patches entries. With the Opencore bootloader, it is possible to use two patches less, because the developers of Opencore have added a quirk not present in Clover. Let's begin 0) algrey - Force cpuid_cores_per_package This patch was first posted by algrey on insanelymac: https://www.insanelymac.com/forum/topic/338516-opencore-discussion/?do=findComment&comment=2762290 https://www.insanelymac.com/forum/topic/338516-opencore-discussion/?do=findComment&comment=2762342 links have been edited few times I think so data could differ a bit. then it was converted by me for Clover and also explained on our forum in several places: this above is the patch that, most likely, is preventing the release of new patches for everyone. Unfortunately it still doesn't work on macOS HighSierra in tests done in private thanks to algrey. 1) algrey - commpage_populate -remove rdmsr 2) algrey - cpuid_set_cache_info - cpuid 0x8000001D instead 4 3) algrey - cpuid_set_cache_info - don't set cpuid_cores_per_package 4) algrey - cpuid_set_generic_info - remove wrmsr 5) algrey - cpuid_set_generic_info - set flag=1 6) algrey - cpuid_set_info - GenuineIntel to AuthenticAMD 7) algrey - cpuid_set_info - jmp to calculations and set cpuid_cores_per_package - 10.15/10.16 😎 algrey - cpuid_set_info - cores and threads calculations - 10.15/10.16 9) algrey - i386_init - remove rdmsr (x3) 10) tsc_init - remove Penryn check to execute default case 11) algrey - tsc_init - grab DID and VID from MSR 12) NoOne - lapic_init - remove version check and panic - 10.16 13) DhinakG - cpuid_set_cpufamily - force CPUFAMILY_INTEL_PENRYN - 11.3b1 now let's go a little deeper. If I activate patch 0 I can deactivate the yellow patches (this is also valid for osx like Monterey beta 1beta 1 (not in macOSHighSierra). If I used opencore bootloader I can also do without the red patches (10,11), this activating a quirk that is unfortunately not present in clover at the moment. quirk is: ProvideCurrentCpuInfo If you have followed this far, it is now possible for you to better understand what Patch 0 does. Its work is done in the same way also in Beta 1, so if you update the present patches and the new ones available for beta 1 accordingly, activating or not the patches 0 you can reduce the number of patches of the family of those marked here in yellow .. and there are also in the latest release of the patches if you proceed to this type of test, refer to find and replace and not to the names of the patches (they often take different names depending on who writes them in their config), it's a bad habit that I have too). I usually try to download the latest official ones, and grab the ones that have the same find and replace that I use in my current working config.plist in use if you have any questions, I will be happy to answer based on my knowledge on this topic good day everyone

lavoro di @Mifjpne poi tuo? o si intende per tuo lavoro o di @Mifjpncancellare delle patches o mettere # davanti a delle voci? tanto per capire! senza polemica poi magari se metti un debug (come ti era stato richiesto ma hai ritenuto di non farlo come da tuo diritto)di quando il disco ti scrive per due minuti e se lo lasci andare scriverebbe dati nel debug ad infinito Questo grazie a come sono stati messi dei maskfind o suggeriti per le patches che avete poi cancellato... magari si capisce il perche' il disco lampeggia (e scrive dati) scrive all'infinito 🙂

hi and welcome here with latest opencore you have a boot menu option to do it otherwise you can do by hand on nvram section of your config.plist I use for my other needs 67000000 you can use others value to achieve this

I am very sorry that this problem has arisen for you, and most likely I have expressed myself badly from the beginning If you have a reduced patch system that starts without difficulty or problems, just adding the patch: Force cpuid_cores_per_package available on insanelymac and published by algrey, it is possible to try to further reduce them by deleting some related to: cpuid_cores_per_package and: cores and logicals count if you use any of them in your small patch set And try to see if you can get any of that type off I am sorry for any inconvenience this may cause you, but I cannot publish the work of others without permission it would be a serious disrespect for the work of others. I hope I have partly clarified the fact that it was created perhaps because of my too much enthusiasm to share things with you on the fly! I will not do it again'!

Clover Patches useful to boot with Big Sur 11.4,11.5 beta 5, 12.x (x=1 and 2) 🙂 Opencore Patches useful to boot with Big Sur 11.4,11.5 beta 5, 12.x (x=1 and 2) list of patches I use in above pictures: new_Algrey Force cpuid_cores_per_package (unreleased in latest form tested today, you can use patch available for now) _cpuid_set_cpufamily - Force CPUFAMILY_INTEL_PENRYN (unreleased) Goldfish64 - Bypass GenuineIntel check panic - 12.0 algrey - _commpage_populate - Remove rdmsr - 10.13/10.14/10.15/11.0/12.0 algrey - _cpuid_set_cache_info - Set cpuid to 0x8000001D instead 4 - 10.13/10.14/10.15/11.0/12.0 algrey - _cpuid_set_generic_info - Remove wrmsr - 10.13/10.14/10.15/11.0/12.0 algrey - _cpuid_set_generic_info - Set flag=1 - 10.13/10.14/10.15/11.0/12.0 algrey - Remove Penryn check to execute default case - 10.13/10.15/11.0/12.0 algrey - Get DID and VID from MSR - 10.13/10.14/10.15/11.0/12.0 algrey - _cpuid_set_info - GenuineIntel to AuthenticAMD - 10.13/10.14/10.15/11.0/12.0 algrey - _i386_init - Remove rdmsr (x3) - 10.13/10.14/10.15/11.0/12.0 XLNC - Remove version check and panic - 10.15/11.0/12.0 this patches: algrey - Remove Penryn check to execute default case - 10.13/10.15/11.0/12.0 algrey - Get DID and VID from MSR - 10.13/10.14/10.15/11.0/12.0 they are not useful if you use a bootloader with ProvideCurrentCpuInfo quirk capability. Personally, my goal was reached by now! always thank to @algrey for his time and skill! 🙂 UPDATE 17-07-2021:

@Ploddles better or no? 🙂 about Monterey but also other system Whatevergreenkext should be disabled or "boot argumetated" well 🙂 if you are using 6900 xt otherwise black screen when login should happen

try this with your EFI I have disabled few patches and added 0 ones UPDATE 17-07-2021:

@Ploddlespost only config .plist you are using to boot in Monterey beta1

@Ploddles my full EFI is always the same! now only a patch is not available and Devs decide when publish it I am helping to debug some stuff if algrey needs to test but all is working fine with latest GitHub AMD OSX patches and algrey one posted here and on insanelymac. obviously without unreleased one beta 2 does not boot with patches available for all is it possible to boot fine from 11.4 to 11.5 beta 5 to 12 beta1 I am trying also to create an interest to have more people helping devs to find patches and test well also in different conditions but my thread has had few success! 😉 Maybe @algrey gave me this chance because I was in touch with him from the first days when patches "was borked" PS it is possible to use Clover Bootloader and Opencore bootloader with the same set of patches (declared in proper way for both bootloader) clover needs two more patches , but as I said before all patches are posted here !

@Ploddlesi am not in touch with shanee as I said I have had it from the creator..😂 @algrey I mean to reduce instead number of patches you have all you need unrealease patch is only for Monterey b2

@iGPU https://pikeralpha.wordpress.com/2016/07/26/xcpm-for-unsupported-processor/comment-page-2/#comment-7296

A long time ago some users who had dual CPU systems with the Xeon 2696 V4 22 cores 22 threads for each cpu for a total of 44 cores + 44 threads, we asked pikeralpha to take an interest in this, and he pulled the location where the kernel declared this limit out of the hat. and it was clearly a value of 3F. It was not possible to modify it in any way and it had to be limited as today by bios, limiting the total number to 64 c / t I don't find where we talked about it, if I find the posts I submit them to your attention If my second dose of Pfizer vaccine doesn't make me crazy, I also remember that we had to patch a kext..but no one has ever succeeded unfortunately and pikeralpha was not very interested in for testing I have changed 1F in 07 but I have in this way a kp in early booting steps

Bonasera a te 🙂

For Opencore and Clover bootloders: algrey - new Force set cpuid_cores_per_package (new version of original available @Inasanelymac) algrey _cpuid_set_info (unreleased) Goldfish64 - Bypass GenuineIntel check panic - 12.0 algrey - _commpage_populate - Remove rdmsr - 10.13/10.14/10.15/11.0/12.0 algrey - _cpuid_set_cache_info - Set cpuid to 0x8000001D instead 4 - 10.13/10.14/10.15/11.0/12.0 algrey - _cpuid_set_generic_info - Remove wrmsr - 10.13/10.14/10.15/11.0/12.0 algrey - _cpuid_set_generic_info - Set flag=1 - 10.13/10.14/10.15/11.0/12.0 algrey - Remove Penryn check to execute default case - 10.13/10.15/11.0/12.0 algrey - Get DID and VID from MSR - 10.13/10.14/10.15/11.0/12.0 algrey - _cpuid_set_info - GenuineIntel to AuthenticAMD - 10.13/10.14/10.15/11.0/12.0 algrey - _i386_init - Remove rdmsr (x3) - 10.13/10.14/10.15/11.0/12.0 XLNC - Remove version check and panic - 10.15/11.0/12.0 --- Published a first version on IM - algrey is improving it (refine its search) --- Unpublished (Useful to boot Monterey b1 and b2) --- Useful in Clover Bootloader and in Opencore Bootloader (if you do not use*: ProvideCurrentCpuInfo Kernel quirk) *Clover bootloader misses that quirk in release 5137/38 used by me! Opencore bootloader quirk I use: Opencore bootloader quirk I use: Clover bootloader quirks I use: I hope it could be useful to understand better!

errori del config.plist che fortunatamente per il tuo sistema non sono gravi devi cercare le voci principali nel config e sistemarle come da manuale tra <> ti da una idea in che sezioni cercare l'errore 🙂

[For Hackers] An utility to search a masked string Maybe an useful utility made by @slice

@dreamwhitenon te lo so spiegare con matematica, ma per installare photoshop ed alcune patches per AMD puo' essere utile la sip Specifico patches per Photoshop! 😉

@Ploddlesnew patches are good for 11.4.x, 11.5 b5 .12 b1 with unreleased single b2 patches all the patches are working also in b2 also with clover

ciao, non c'e' un motivo..sto provando cose con clover! comunque in generale non ho problemi con qualsiasi valore di quelli noti

fatto lavorare le nuove Patches anche su beta 5... tutto ok! 🙂 anche le "vecchie" vanno" nessun problema

beta 5 is up 🙂

@iGPUgreat catch,, I think should be good 1F like we do...we miss @meina222he could test this and maybe it could be very useful without lock cores on bios..if 1F works as I think

it seems you have had succes If not contact an admin thank you

Non chiedete come 🙂 ringrazio @algrey che mi ha fatto provare in anteprima la patch per beta 2

Hi @sileshnyou have a minimal of one or two message before it is unlocked automatically welcome here
