Build - Asus ROG X670E Hero + AMD Ryzen 9 7950X + AMD Radeon RX VEGA 56

[luchina]

After a lot of work and a lot of help from @fabiosun and @Lorys89, the monster is finally ready! Thank you very much for your help!



Asus ROG X670E Hero + AMD Ryzen 9 7950X + AMD Radeon RX VEGA 56





Component Versions



• macOS: Sonoma 14.1.1
• Opencore: 0.9.6
• AMD Kernel Patches: Latest from https://github.com/AMD-OSX/AMD_Vanilla
• BIOS: 1602



Some Notes



• Latest BIOS 1709 or higher, DSDT patch required, developed by @Lorys89 - Pls inject this DSDT.aml and set Enable/True RebaseRegions in config.plist
• This EFI is compatible with Intel Wireless and Bluetooth (onboard Wi-Fi 6e AX210) for macOS Ventura and Sonoma
• USBMap (corpnewt) method



For BIOS newer or equal to v1709



• Post reference

Benchmarks



- Speedometer v2.1



- Geekbench v5 & v6

https://browser.geekbench.com/v6/cpu/3609806

https://browser.geekbench.com/v5/cpu/21961976



- Dehancer Benchmark / Davinci



- CPU Endurance for 10 minutes



- Cinebench R23



- Cinebench 2024 (CPU & GPU)

- Blackmagic RAW Speed Test



- Blackmagic Disk Speed Test



- Amorphous Memory Speed Test



Edited November 19, 2023 by luchina

[luchina]

Copy/Download of EFI



EFI-OC096-ASUS-ROG-CROSSHAIR-X670E-HERO-AMD-RYZEN-9-7950X-RADEON-VEGA-56.zip



Important



- EFI without kexts for Wireless because of the file size limit here on the forum;

- Download of AirportItlwm for Sonoma: https://github.com/OpenIntelWireless/itlwm/releases/download/v2.3.0-alpha/AirportItlwm-Sonoma-v2.3.0-DEBUG-alpha-ff1138b.zip

- Download of AirportItlwm for Ventura: https://github.com/OpenIntelWireless/itlwm/releases/download/v2.2.0/AirportItlwm_v2.2.0_stable_Ventura.kext.zip

- Pls rename this files for "AirportItlwm-Sonoma.kext", "AirportItlwm-Ventura.kext"  and copy to Kexts directory in EFI/OC/Kexts



Edited November 19, 2023 by luchina

[Lorys89]

Add kext smc super io and SMCProcessorAMD and disable 2 kext SMCAMDProcessor and AMDRyzenCPUPowerManagement

https://github.com/Lorys89/SMCProcessorAMD/releases/download/1.0.1/SMCProcessorAMD-1.0.1-RELEASE.zip

[luchina]

2 hours ago, Lorys89 said:

Add kext smc super io and SMCProcessorAMD and disable 2 kext SMCAMDProcessor and AMDRyzenCPUPowerManagement

https://github.com/Lorys89/SMCProcessorAMD/releases/download/1.0.1/SMCProcessorAMD-1.0.1-RELEASE.zip



I don't know these new kexts.



Do they support using the AMD Power Gadget app?

When you say SMCSuperIO, is it the one that comes with VirtualSMC package? Or is it some other variation?



Thanks 😉

[fabiosun]

@luchina



@lorys89 repo has a modified kext to work well with AMD system

Original kexta is not updated for us
