fabiosun

what works 1) thunderbolt 4 (Maple Ridge chip)* 2) internal RealTek 2.0 audio (as the thread ripper but without thread ripper detection problem) 3) hdmi/DP audio 4) all usb internal and motherboard 3 USB 2 header, 2 USB3 header (ASMedia) 5) All 4 NVME slots 6) intel i225 Ethernet 7) All 6 sata ports (two different controllers one is ASMedia) 8] sata hotplug 9) sleep/wake 10) Continuity Cam * *NOT Hot Plug for now what doesn't work in my specific case all Sata disks are seen as external and at the moment it was not possible to have them internal with kext or settings for Device properties that I tried Solved it was an incompatibility with Ventura OS device enumeration The system is as stable as the previous one I had Temperatures in full load are higher, in idle or medium load much but much lower In Ventura my Pioneer Blu ray disk recorder is not seen by OSX solved with a os update, in Monterey it works is it worth it? for me yes in full load I lose, compared to a TRX 3970x, about 15 %. In tasks that do not involve using all cores I gain even 20% With Davinci Resolve, using the test benchmark (candle). With trx40 I had for: 66 nodes 30/31 fps 6 TRN nodes 40/41 With AM5 I now have: 66 nodes 31/32 fps 6 TRN nodes 48/49 In general use I don't see much difference with my previous platform, lower watts and temperatures (not in full load) The bios is still very immature (0922 bios is a good improvement) but, if I hadn't made mistakes in assembly the system would have been up in an hour I would not spend too much on expensive DDR5s at very high frequencies since from AMD specs if you fill all 4 slots the maximum frequency is 3600! With latest Bios 0925/1003 is it possible to push 4 Dimm to 4800 without problems *https://github.com/acidanthera/FeatureUnlock/actions/runs/4398382993

yes for AM5 and trx40 platform I use the same boot arg

Yes!

I am pretty happy for now in task I use like davinci is often faster than thread ripper about 20% only 128 gb is possible but it is enough half the cores of a 3970x

You do not need anymore of these files use AMDFriend script to patch them easily

First EFi I have posted which starts to be interesting Added in first post a "perfect! working EFI

cabinet thunderbolt with a NVME samsung 🙂 on TB4 of Hero motherboard! 🙂 🙂

On AM5 platform? yes it works perfectly (USB /HDMI(DP or also with audio which needs applealc) My motherboard has (as thread ripper motherboard) Realtek USB2.0 audio It is improved because I can boot with speaker inserted and I have working audio while thread ripper has this problem

Si ora sono scese ma va bene

you could enable also only the first one of this ands sorry for error I was on my moonier and maybe I did errors before in conversion

Config-8.plist.zip try this and see if in the bootleg first four MMIO areas became skip 1 now

post config plist you use in this debug without your serial

33:245 00:001 OCABC: MMIO devirt 0xD2100000 (0x81 pages, 0x8000000000000001) skip 0 33:246 00:001 OCABC: MMIO devirt 0xD3180000 (0x81 pages, 0x8000000000000001) skip 0 33:247 00:001 OCABC: MMIO devirt 0xD9180000 (0x81 pages, 0x8000000000000001) skip 0 33:248 00:001 OCABC: MMIO devirt 0xD9300000 (0x100 pages, 0x8000000000000001) skip 0 33:249 00:001 OCABC: MMIO devirt 0xDA100000 (0x181 pages, 0x8000000000000001) skip 1 33:250 00:001 OCABC: MMIO devirt 0xFEA00000 (0x100 pages, 0x8000000000000001) skip 1 33:252 00:001 OCABC: MMIO devirt 0xFEC00000 (0x1 pages, 0x8000000000000001) skip 1 33:253 00:001 OCABC: MMIO devirt 0xFEC10000 (0x1 pages, 0x8000000000000001) skip 1 33:254 00:001 OCABC: MMIO devirt 0xFED00000 (0x1 pages, 0x8000000000000001) skip 1 33:255 00:001 OCABC: MMIO devirt 0xFED40000 (0x5 pages, 0x8000000000000001) skip 1 33:256 00:001 OCABC: MMIO devirt 0xFED80000 (0x10 pages, 0x8000000000000001) skip 1 33:257 00:001 OCABC: MMIO devirt 0xFEDC2000 (0xE pages, 0x8000000000000001) skip 1 33:258 00:001 OCABC: MMIO devirt 0xFEDD4000 (0x2 pages, 0x8000000000000001) skip 1 33:259 00:001 OCABC: MMIO devirt 0xFEE00000 (0x100 pages, 0x8000000000000001) skip 1 33:260 00:001 OCABC: MMIO devirt 0xFF000000 (0x1000 pages, 0x8000000000000001) skip 1 33:261 00:001 OCABC: MMIO devirt 0x10000000000 (0x10400 pages, 0x8000000000000001) skip 0 33:263 00:001 OCABC: MMIO devirt 0x3CB80000000 (0x10400 pages, 0x8000000000000001) skip 0 33:264 00:001 OCABC: MMIO devirt 0x3CBB0000000 (0x10400 pages, 0x8000000000000001) skip 0 33:265 00:001 OCABC: MMIO devirt 0x69730000000 (0x10400 pages, 0x8000000000000001) skip 0 first four are wrong you have to adjust properly maybe some bios adjustment you did or some new device added on motherboard

@shrishahi we need your open core debug txt to check if MMIO is different

Yes i have sold it new adventure now less work to do because @CaseySJdid a wonderful job

WhatsApp Video 2023-01-19 at 18.04.22.mp4

Ah non in pvt! altrimenti le ram me cancellano pure i messaggi 😂

Al momento le ho provate tutte A chi?😂 a me no

adieu 🙂 GoodBye 🙂 Ciao 🙂 (joking a bit)

sorry for the delay I see onlyy now if you use the EFI posted in OP you have to change core count number in your EFI config plist kernel patches section

tie allora ti frego io ho aspettato tanto ma se non ti decidi! 🙂 😛 ho problemi seri di RAM non guardate qui che dice 128 a causa della memoria mappata Il sistema parte e funziona perfettamente solo con una memoria installata in uno slot nemmeno consigliato per il singolo modulo chissà cosa e' rotto La cos che mi lascia dubbioso e' che la macchina funziona normalmente con un solo modulo con piu' non posta

full installer qui (runmedownloader) e nei soliti posti

After a few years where I enjoyed and used my ThreadRipper with immense satisfaction, I made the decision to venture into another project. This time taking advantage of the tremendous work done by @CaseySJand other users, I will struggle much less to get my PC working than we suffered three years ago for TRX40 Motherboard: https://rog.asus.com/it/motherboards/rog-crosshair/rog-crosshair-x670e-hero-model/ CPU: AMD Ryzen 7950X https://www.amd.com/en/direct-buy/5676499200/it 128 Gb DDR5: 2kit of Kingston Fury Beast DDR5 RGB 64GB (2x32GB) 5200MT/s DDR5 CL40 DIMM https://www.amazon.it/gp/product/B0B1QNPM2T/ I will keep the CPU heatsink and some of the disks that I have now This system loses in multicore to my TRX40 but performs better in other areas I hope to see you still developing our historical thread on the TRX40, I certainly will a touched TrexIntosh 🙂 🙂 SysReport.zip EFI_ASUS_ROG_x670E_HERO_Clover5149.zip EFI_ASUS_ROG_x670E_HERO_OC_098.zip EFI-ASUS_x670E_HERO_Bios2124-fabiosun.zip
